Specifications：

LVDS Interface	SerDes	√
	Maximum Transmission Rate	625Mbps
	Number of Interfaces	2 pairs * Input, 2 pairs * Output
Output	TTL	√
Output	Data Sets	6
Spread Spectrum Capability	High
Independent Module Activation	Support
ADC	Channels	3
	Sampling Rate	100Ksps Sampling Rate
	Sampling Depth	12bit Sampling Depth
Communication Bit Error Rate	√
Package	LQFP40
Flash Capacity	32Mbps

Comparison：

Type	Interfaces	Output Data Sets	ADC Channels	Flash Capacity	Independent Module Activation	Package
TBS614E	2 pairs * LVDS input, 1 pairs * LVDS output, data input interface transmission rate 166Mbps ~ 572Mbps	4	1	8M	Not Supported	QFN40
TBS614S	2 pairs * LVDS input, 1 pairs * LVDS output, data input interface transmission rate 166Mbps ~ 572Mbps	4	1	16M	Not Supported	QFN40
TBS615S	1 pairs * LVDS input, 1 pairs * LVDS output, fixed data input interface transmission rate: 625Mbps	4	1	16M	Support	QFN40
