Specifications：

Basic Info	Interfaces	RGMII	√
		LVDS	-
	Loading Capacity	640x360@60Hz Brightness and Chroma Calibration
	RGB Parallel Data Sets	32
	Input Video Source	8bit	√
		10bit	√
		HDR/HLG	√
	Package	BGA213
Display Effect	Frame Rate Adaptive 2.0	√
	Image Booster	Color Management	√
		Precise Grayscale	√
		18Bit+	×
		22Bit+	√
	Pixel-by-pixel Brightness and Chroma Calibration	√
	Full Grayscale Calibration	√
	Self-adaptive Calibration	√
	Driver IC low-grayscale Calibraion	√
	Rapid Seam Correction	√
	3D	√
	RGB Independent Gamma Adjustment	√
	Multiple Rotation of 90°	√
	Three-light and four-light Virtual Pixels	√
Maintainability	Special-shaped Cabinet	√
	Arbitrarily Data Sets Exchange	√
	Mapping	√
	Self-testing	√
	Prestored Image	√
	Temperature and Voltage Monitoring	√
	Cabinet LCD Monitoring	√
	Error Detection	√
	Configure Parameter Read-back	√
	Loop Backup	√

Comparison：

Type	Cascade Interfaces	Loading Caoacity	Output Date Sets	Display Algorithm	Package	More
TBS6332	RGMII	512x512@60Hz	32	Pixel-by-pixel Brightness and Chroma Calibration, Seam Correction	BGA213
TBS6335	LVDS	640x360@60Hz	32	Pixel-by-pixel Brightness and Chroma Calibratio, Seam Correction, Image Booster, Driver IC low-grayscale Calibraion	BGA213
